Homebrew: macOS Big Sur and ARM
Changes needed to work on Big Sur and to support a new CPU architecture.Presented at FOSDEM 2021.
Show transcript
- 0:00 Hi everyone, welcome to my semi-talk. It feels strange after doing these for so many Fosdems
- 0:09 in a row to be sitting at my house by myself trying to do this. Excuse any misspeakings,
- 0:17 I had my wisdom tooth out yesterday so things are a little bit ropey. And excuse any mess
- 0:24 in the background as this is my lovely home office in Edinburgh in Scotland.
- 0:30 Well thank you for joining me today. I'm going to be talking about Homebrew as usual and the macOS
- 0:38 Big Sur and ARM also known as Apple Silicon and how Homebrew has adapted to support both of these.
- 0:46 Now through this talk I'll be using ARM mostly when referring to Apple Silicon even though that's
- 0:53 not what Apple calls it. This is just because it's a bit simpler for me and it fits more easily on the
- 0:59 slides. So those of you who haven't come across me before, nice to meet you. My name is Mike McQuaid,
- 1:05 here's some of the ways you can kind of contact me. I'm on GitHub and my username on GitHub and on
- 1:17 Twitter is the same, Mike McQuaid, just the same as my name. I'm an employee at GitHub as well,
- 1:21 I've been there about seven years. I'm a staff engineer working on communities. So feel free to get in
- 1:27 touch with me after this talk if you have any questions about Homebrew or GitHub or you want
- 1:32 to discuss anything in particular. But let's get on with things. Right so macOS Big Sur is the first
- 1:41 version of macOS that has adopted a new versioning model since OS X was originally released
- 1:50 a long time ago and this is interesting for us for a few reasons because we've had to deal with various
- 1:58 ups and downs through the betas. So in the first beta we had macOS 10.16 Big Sur which was the version that we
- 2:08 saw being used. So 10.15 was the previous version that we were supporting known as Mojave and this
- 2:18 looked kind of like it was all going to be fairly normal. But then stuff started showing off in some
- 2:22 of the betas with macOS 11 and then in the initial ones it seemed to be a difference between 16 in some
- 2:29 places and 11 in other places and this was differentiated by 10.16 for the Intel betas and 11 for the ARM or
- 2:41 Apple Silicon betas. And this obviously was fun in itself because you have two different versions that
- 2:48 refer to the same thing from our perspective. And also with the 11 it's been 10 point whatever for
- 2:56 I think 12 years at this point. Maybe a bit longer actually I think maybe 15 or 16. I can't tell off the
- 3:03 top of my head. And yeah there's a lot of regexes out there that assume a macOS version is going to be
- 3:09 10 point something. So I immediately saw this and thought uh oh this is going to break a ton of regexes.
- 3:15 But where it gets even more fun is we're now on macOS 11.1 Big Sur. So previously you had 10.16
- 3:23 0.1 0.2 0.3 whatever would be the way they would have done their releases.
- 3:30 And that meant that we could kind of track the different versions and the major minor
- 3:35 versioning was kind of consistent. And we thought okay well if they move to this 11 model then it'll
- 3:40 effectively be just the same as before but they will shift things slightly. And instead what they've
- 3:46 done is Apple have decided to have different SDKs per minor version of the OS. So whereas previously
- 3:53 they would have just had a 10.15 SDK and a 10.16 SDK now they have an 11.0 SDK and 11.1 SDK.
- 3:59 So again this is solvable stuff but there's a huge amount of assumptions in homebrew and various build
- 4:07 scripts that things are not going to work this way. And homebrew ends up acting as a bit of a kind of
- 4:13 glue layer for a lot of projects. So we abstract away and fix in the build system some of the things where
- 4:21 people pass you know SDKs that are no longer around selecting the right SDK based on the OS based on the
- 4:28 compiler you're using all this type of stuff. So this causes a bit of fun and hiccups and we're still
- 4:34 slightly figuring this out but I think we've got to a point now where we're pretty stable and we have
- 4:39 something which works reliably going forwards. So the next big change that we saw was the arrival of Apple
- 4:46 Silicon which I'm referring to as ARM throughout this. So Apple announced that a few people had sort of
- 4:54 suspected this was coming for a while but their own custom in-house architecture that they were going
- 5:00 to use that they had built for new Macs. So the interesting thing with this, sorry give me one sec.
- 5:07 The interesting thing with this was that it was going to require us to fix a bunch of homebrew code to no
- 5:20 longer make assumptions about what platform things are running on. So I'm sorry but by platform there I
- 5:27 mean architecture. So for a while homebrew has been Intel x86 only but this hasn't always been the case.
- 5:34 And so on Mac OS X when it originally was released for the first versions they were all running on
- 5:41 PPC 32 processors and I believe then there was PPC 32 and 64. So that's the power PC architecture that
- 5:49 Apple used to use. I believe some folks out there are still kind of running power PC chips but you
- 5:54 certainly don't see as much of them nowadays as you used to. And when Apple was shipping these two
- 5:59 versions at once they used what they called their I guess universal support where they would ship
- 6:05 fat binaries, their words not mine, basically binaries where they've been built for each
- 6:11 architecture and they've been kind of glued together with a tool called LiPo. Again it feels like a pun
- 6:18 intended there and those architectures are glued together in a single executable say or library
- 6:25 so when you run the executable it will select based on the architecture that is what your current CPU is
- 6:31 in your machine. So then after that Apple made the migration from PPC to Intel chips. They previously
- 6:40 made a move from a different Motorola architecture in the past to the PPC. So Apple at this point have made a few
- 6:47 architecture jumps over the years. So their way of handling this which I'll touch upon later on as
- 6:53 well was to have a thing called Rosetta which let if you had an x86 laptop you could still run some of
- 7:01 the PPC code because it's a completely different architecture it's not backwards compatible in any
- 7:06 sort of meaningful way. So they again provided these fat binaries with x86 as well and this was about the sort of time
- 7:14 where I had first started using a Mac I first started using a Mac in I think it was 2008 or 9 or something
- 7:23 and Macs were x86 and when I got involved with homebrew Apple was just starting to explore x86 64 with
- 7:34 Mac OS 10.6 Snow Leopard where they were providing 64-bit support for the first time. There was a bit of 64-bit
- 7:41 support in Leopard 10.5 but that was kind of minimal enough and it was you had to kind of use a few kind
- 7:47 of hacks to get working so not many people were distributing stuff there. So this was homebrew
- 7:52 supported both Leopard and Snow Leopard so we had to start dealing with kind of multiple architectures at this point
- 7:59 and in the early homebrew days as well we were a lot more of a compiling from source package manager we
- 8:06 had extensive options we had no CI and a much much smaller number of users who didn't really expect
- 8:11 things to work all the time so we provided a lot of customizability for people to be able to select
- 8:15 for some software to be able to build say all four of these architectures at once but then pretty soon
- 8:21 Apple were getting to the point where they were dropping their PPC stuff they didn't support Rosetta
- 8:24 anymore I forget what version they dropped that on and they were so we're going to just x86 and x86.64
- 8:31 and then before you know it we're just down to x86.64 so this has been probably a pretty long time for
- 8:38 homebrew that there's been no Macs that we or at least no Mac versions that we support that have any support
- 8:45 for x86 and or at least have no at least all of these Macs can run x86.64 code so we've been steadily sort
- 8:55 of um focusing on shipping macOS for a single architecture but I think we always suspected
- 9:01 something like this could happen in future and also not wanting to deliberately tear out a bunch of the
- 9:06 code before so we did tear out the code to build multiple architectures that universal support
- 9:12 that we talked about but we always kept around code letting homebrew be multiple architecture
- 9:17 friendly because although we don't support it we have some people who run homebrew on raspberry pies
- 9:22 and on PPC chips and stuff like that still so we thought we'd keep that around and that's obviously proved
- 9:29 useful to us now that we now have ARM64 aka ARM aka Apple Silicon which is where we are today so
- 9:39 we are now having to support homebrew on two architectures we're shipping binaries for two
- 9:45 architectures uh this is probably this is in fact yeah it is the first time that we have had CI for
- 9:51 multiple architectures both running the same OS and building the same thing in different configurations in
- 9:56 different places so that's been sort of interesting and it will be interesting to see how that kind of
- 10:01 challenge goes on in future so I mentioned in the past there was Rosetta which was I guess a reference to
- 10:08 the Rosetta Stone and and that allowed you to run PPC code on x86 so nowadays we have with the new
- 10:17 ARM Apple Silicon Max we have what Apple call Rosetta 2 which is what lets you run x86 64 code I don't believe
- 10:24 x86 code but I could be wrong there and it lets you run that on ARM so the benefits of that is you still have a certain amount of
- 10:34 AQUIS compatibility of those programs that haven't been ported yet and unlike in the old days with Rosetta
- 10:41 homebrew sort of just pretended that didn't exist whereas now we've actually doubled down a little
- 10:45 bit more and we're trying to work around Rosetta 2 to provide a nicer user experience for our users
- 10:51 so if you've been using homebrew on Mac particularly for a little while you've known that we've used user local for a long time
- 10:59 as a default installation location so the reasoning for this is because it lets you pick stuff up in
- 11:06 your compiler paths automatically it didn't used to be used for anything although more and more stuff
- 11:10 dumps things in there and it basically just was a nice easy location that we could use
- 11:17 so we've used that for a long time we've we've had sort of sporadic backlash about that some of which is
- 11:22 valid saying well this location is used by other tools so we can maybe avoid it and some of it is
- 11:29 invalid with asking people people getting very upset about changing the permissions and suggesting that
- 11:34 you install it in home instead because in my opinion that is an invalid viewpoint to be concerned about
- 11:41 because if you're concerned about your package manager being human readable and someone getting access
- 11:46 to be able to run an arbitrary coding machine then you probably care about the fact that they can destroy or
- 11:51 edit or modify all your documents and such like anyway but anyway moving on so homebrew on linux has a
- 11:59 slightly different default location and these default locations are not only where the installer will
- 12:05 install things for you but these are where the majority of the binary packages work some binary packages we
- 12:10 have are what we call relocatable so that means you can install them in a homebrew installation anywhere
- 12:17 and we can just modify the references in there and they can work anywhere but a non-relocate non-relocatable
- 12:24 binary package bottles we call them mean that unfortunately you have to use the specific
- 12:31 supported location so user local or in linux home linux brew linux brew looks i'll explain why in a minute
- 12:38 you have to use that location if you want to get the binary packages and as we are mainly a binary package
- 12:42 manager nowadays that's what we strongly recommend and that's arguably all we support so if you install
- 12:47 in a different location and that works for you then great if you install a different location you have
- 12:52 problems with builds and such like then we're unlikely to fix your problems unfortunately
- 12:55 so the linux location the reasoning for that is because um homebrew on linux
- 13:04 has quite a lot of users maybe the majority of the original sort of users but back when it was called
- 13:10 linux brew were on sort of scientific computing environments where they may well have a bunch of
- 13:16 stuff on big scientific computing clusters and they have access to a home directory on their machine but
- 13:23 they can't use the native package manager so linux brew was useful to be able to install bits and pieces on
- 13:27 those machines and a few of those folks found that it was relatively easy to ask your sys admins for
- 13:34 those machines because you normally don't have root on them if you're a scientist working on them and if
- 13:39 you get access to those machines to be able to create a new user called linux brew and then you can get
- 13:44 write access to their home directory then you can use this default installation location which can be shared
- 13:50 between multiple users on the same machine without needing root access for any of them and have binary
- 13:54 packages that can work in this location so i mentioned before the stuff with rosetta 2
- 14:01 and about how we're trying to support that a little bit better than we did before
- 14:05 so as part of that because there's this transparent x86 compatibility layer and because of our packages
- 14:13 being installed in user local and not being really capable outside of that we wanted to have a way to allow
- 14:20 people until homebrew and arm is significantly more established and until binary packages are fully supported for everything
- 14:29 we wanted to have a way for people to kind of have a fallback that would still work nicely for them which didn't involve building from source
- 14:35 so homebrew and arm has a new default installation
- 14:39 default installation location which is opt homebrew
- 14:45 so again that looks a little bit like mac ports we can tip our hat to them and say thank you for the
- 14:49 inspiration there and this is a new location that we're we're using everything will be all encapsulated
- 14:56 there it's pretty obvious that everything in there will just be homebrew and there is where the binaries on
- 15:02 arm are going to be built for and we have now some minor restrictions on installation locations which we didn't have before
- 15:10 so if you try and install under arm into user local or try and install intel under opt homebrew we now
- 15:17 won't let you and the reason for that is we want to provide
- 15:20 the support to effectively use if you're on an arm mac now the m1 chips i think they call them
- 15:27 and then in user local we want to reserve that for a rosetta 2 installation of homebrew so that
- 15:33 means you can have an installation in user local and an installation in opt homebrew and the two of them
- 15:38 will play nice with each other they will use the correct binary packages and they won't get
- 15:41 confused and start trying to link against the other one so now we've got to a point where that allows
- 15:48 people we have about a third i think of the usage from analytics data so far for this rosetta 2 still
- 15:54 the most people on our max are still just using this completely native location and they're finding
- 15:58 that that works pretty well for them i'll talk about what the breakdown is shortly but if not you can
- 16:04 use user local and there's some people it seems who just use that for everything because they don't
- 16:08 want to deal with the hassle so obviously there'll be a slight performance benefit well it depends on
- 16:13 the software you're running but for um natively compiled software there will be some degree of
- 16:18 performance benefit for running the natively compiled on binaries so that's beneficial and we would like to
- 16:25 sort of recommend that but then the user local rosetta 2 is a good fallback as well
- 16:30 so bottles these binary packages i mentioned so a bottle block for one of our packages looks a little
- 16:35 bit like something like this so you can see now this is basically all the supported versions we have
- 16:40 now there are some versions where we try if the package isn't upgraded and we release a new version
- 16:44 of mac os we try and just add the new binary package rather than removing any old ones so this is a tool
- 16:50 that has all the supported versions of homebrew on mac os right now so we've got big sir arm 64 big sir
- 16:57 catalina mojave high sierra sierra el capitan yosemite and mavericks going all the way back so
- 17:04 the arm binary packages are just handled like any others we've got this arm 64 big sir we'll probably
- 17:10 continue that sort of naming format until we have at some point in the future we'll have a mac os version
- 17:16 where they don't support intel anymore that seems fairly inevitable based on the way they've dealt
- 17:20 with migrations in the past so until then we're just going to continue adding and trying to build
- 17:26 these packages so how's that effort going for arm well as i mentioned before not everything is available
- 17:32 yet for arm and we've got our arm ci which is a nice kind of collaboration between three companies that
- 17:38 have helped us out here so github actions we've now replaced all our jenkins
- 17:43 installation that was our cause of security vulnerabilities for us in the past and just
- 17:48 generally we didn't have the decent amount of admin staff to be able to actually keep that up and
- 17:52 running well so we're using github actions for most of our ci and then for actually building the binaries
- 17:58 themselves we've got our own workers in mac stadium so mac stadium have generously provided us with
- 18:06 um various vms for our macs in the past so that's where we've been running our um intel workloads for
- 18:12 a few years and then now apple supplies with some dtks that's um i forgot what that stands for but
- 18:18 basically their arm kind of developer kits um and hopefully in future ones those have to be returned
- 18:24 to apple we'll be able to get some mac minis or similar off them as well so that we can run this um
- 18:31 arm ci so if you go and submit a homebrew package or change to the homebrew core repository now it will
- 18:37 now be running github actions uh on a apple ddk hosted by mac stadium to build our binary packages
- 18:44 the same way we do with intel ones so we've got at the moment we've got at my time of checking last at
- 18:51 least uh 4615 intel big sur bottles so that's essentially all the packages that need binary
- 18:58 packages and are working on big sur for intel which is you know pretty much everything and then we have
- 19:05 3850 for arm slash apple silicon so we're we're not fully there and there's obviously going to be stuff
- 19:12 that's missed but for a good number of people it does seem that they're um able to install everything
- 19:17 they want to install and get that all working on arm without the need to kind of fall back on the
- 19:23 intel stuff so this has actually gone a lot quicker than i expected and it's been i'd like to give a
- 19:29 particular shout out to fx cuder who is one of our maintainers who's been doing a lot of work on this
- 19:35 um and particularly on the kind of packaging side and bottling side getting this all up and running so
- 19:40 great work to everyone who's taking part in that and all the other homebrew containers
- 19:45 who've kind of chipped in on the arm work as well so if you're wondering which of those bottles apply
- 19:51 to you or not and you wanted to kind of check maybe before you buy an arm mac or before you're sort of
- 19:56 making sort of decisions around this stuff then you can go on to formulae.brew.sh that's our main
- 20:02 website now for hosting the stuff and as of today um eric has just added one of our other maintainers
- 20:09 like nicely formatted stuff providing the detail of what the support is so you can see for open ssl 1.1
- 20:15 we provide binary packages for big sir catalina mojave on intel and big sir for apple silicon
- 20:21 and that details basically that okay we have a binary package there that means the package will work
- 20:27 or at least should work um to the and we will support that to the same extent as intel so we will treat
- 20:33 things not working there not compiling as well sorry not not compiling things not working with
- 20:39 the binary package we'll treat that as a bug and we will try and endeavor to fix them in the same way
- 20:43 as we would for intel so from that perspective i can announce today that homebrew on arm slash apple silicon
- 20:51 is officially supported if you submit issues we will prioritize them the same way as we would do with
- 20:56 intel ones and obviously we have limited amounts of maintainers who have arm hardware so it may not be
- 21:02 quite as easy for us to fix these but we will still endeavor to do so and this also brings us along to
- 21:09 the fact that we're calling this homebrew 3.00 so this has been a pretty big deal getting all
- 21:15 the arm support working and it feels like a major milestone for homebrew that we've been able to do so
- 21:19 relatively quickly and announce official support so i'm happy to announce homebrew 3.0 and now hopefully
- 21:26 you've enjoyed watching this video and i should be assuming that my children are not interfering with
- 21:33 my life too much i should be in the matrix chat now and i can answer any questions so thanks for joining me
- 21:38 goodbye
